- High Precision Universal Testing With maximum load options up to 20KN and accuracy class 0.5, this machine delivers reliable tension, compression, bending, shear, and peeling tests for metals, plastics, rubber, and composites.
- Offers test speeds from 0.01-500mm/min and effective tensile space up to 800mm (customizable), with displacement accuracy within ±0.2% and real-time data capture.
- Advanced Servo & Control System Powered by TECO/Panasonic servo motors and high-precision ball screws, ensuring smooth operation. Embedded controller supports automatic stress, elongation, and modulus calculation.
- Meets ASTM, ISO, and DIN standards such as ASTM D638, ISO527, and ISO178, suitable for quality inspection across industries including automotive, textiles, and building materials.
- User-Friendly & Expandable Features PC-based curve display, data analysis, and report printing. Expandable with multiple load cells and deformation measurement systems for tailored testing needs.
Main Features:
The main controller adopts the most advanced 32-bit ARM processor in the 21st century, and its processing speed reaches the level of a Pentium-level general-purpose computer. Compared with the traditional 8-bit single-chip microcomputer measurement and control system, the overall performance is greatly improved, the operation speed is faster, and the control accuracy is higher.
The core device of data acquisition adopts the latest ultra-high-precision 24-bit AD in the United States, and the sampling rate can reach 2000 times per second, which can capture the instantaneous change process of power. And the original 6-point calibration technology is used to further improve the accuracy, and the force measurement accuracy is better than the national 0.5 level (the highest level) standard.
The counting of the displacement encoder adopts the 4-fold frequency technology, which increases the displacement resolution by 4 times, up to 0.0005mm.
There are two output control modes of pulse and voltage, which can control any servo motor, variable frequency motor or DC motor with pulse or voltage control interface to achieve smooth stepless speed regulation. In addition, there are switching signal outputs such as up, down and stop, which can be used directly. Drive external relays or solenoid valves, which can be used to control DC motors or pneumatic, hydraulic and other power devices.
Advanced speed, displacement and force three closed-loop technologies can realize precise arbitrary waveform control.
Rich interface expansion capability: up to 4 channels of 24-bit analog input, 3 channels of 16-bit analog output, 3 channels of pulse output, 3 channels of AB phase photoelectric encoder input, 9 channels of digital input, 8 channels of digital output, 1 USB interface, 1 RS232 interface, 1 RS485 interface, 4 LCD interfaces, 1 parallel micro-printer interface, 1 serial micro-printer interface, 1 8×4 matrix keyboard interface.
All input and output interfaces adopt high-speed photoelectric isolation technology, which has strong anti-interference ability!
Technical Parameters:
| Model |
ZL-8001A |
| Maximum Load |
Optional within 100N, 200N, 500N, 1KN, 2KN, 5KN, 10KN, 20KN |
| Accuracy Class |
Level 0.5 |
| Effective Force Range |
0.4%～100% (Level 0.5) |
|
Force
Measurement Accuracy
|
Within ±1% of indicated value/Within ±0.5% of indicated value |
|
Testing Machine
Resolution
|
The maximum load is 1/200000, there is no division between inside and outside, and the resolution remains unchanged throughout the process |
| Load Cell |
Basic configuration: one tension and pressure sensor (maximum load)
Extended configuration: multiple sensors can be added
|
| Effective Test Width |
390mm (can be widened according to customer requirements) |
| Effective Stretching Space |
400, 500, 600mm, 800mm (can be increased according to customer requirements) |
| Test Speed Range |
0.01～500mm/min |
| Displacement Measurement Accuracy |
Within ±0.5% of indicated value/Within ±0.2% of indicated value |
