ISO 11925-1 ISO 11925-2 Flammability Test Equipment Building Material Inflatability Testing Machine with Single Flame Source

Large Image : ISO 11925-1 ISO 11925-2 Flammability Test Equipment Building Material Inflatability Testing Machine with Single Flame Source

Product Details:

Place of Origin:	China
Brand Name:	ZL
Certification:	ISO
Model Number:	ZL-3060

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	USD 1,200.00 - 1,500.00 / unit
Packaging Details:	ISO 11925-1 ISO 11925-2 Flammability Test Equipment Building Material Inflatability Testing Machine with Single Flame Source will be Packaged in wooden case （fumigation free）
Delivery Time:	7-10 days
Payment Terms:	T/T,L/C,Western Union
Supply Ability:	100 set per month

Contact Now

Detailed Product Description

Name:	ISO 11925-1 ISO 11925-2 Flammability Test Equipment Building Material Inflatability Testing Machine With Single Flame Source	Model:	ZL-3060
Ambient Temperature:	15 ° C ~ 25 ° C	Relative Humidity:	≤ 85%
The Burner Diameter:	Φ0.17mm	Burner Can Be Tilted:	45°
Apply Flame To The Sample:	1s-99 S ±0.5s
Highlight:	ISO 11925 flammability test equipment , building material flammability testing machine , single flame source flammability tester

ISO 11925-1 & ISO 11925-2 Flammability Test Equipment

Building Material Inflammability Testing Machine with Single Flame Source

Product Overview

This advanced flammability test equipment features touch screen control and stainless steel construction. Built as an upgraded version of the JCK-2 model, it incorporates automatic sample lifting, adjustable Bunsen burners, and strict compliance with national standard GB8626-2007 for building material combustion grade testing.

Application Scope

The building material flammability test furnace measures material combustibility by directly impacting vertically placed samples with small flames in normal combustion environments. Utilizing the German Kleinbrenner principle, it evaluates the combustion properties of Class B building materials under direct flame impact for flame retardant grade B level determination.

Compliance Standards

ISO 11925-2:2002 E - Test method for flammability of building materials
GB/T 8626-2007 - Test method for flammability of building materials

Technical Specifications

Ambient Temperature	15°C ~ 25°C
Relative Humidity	≤ 85%
Supply Voltage & Power	220V 50HZ 100W
Gas Source	Commercial propane with purity ≥ 95% (liquefied petroleum gas acceptable with user safety provisions)
Flame Application Time	15 seconds to sample
Control System	Single-chip control with digital display
Burner Specifications	Diameter Φ0.17mm, flame length 20mm±2mm, burner tilt capability 45°
Flame Timing	Adjustable 1-99 seconds ±0.5s with ±0.2s accuracy
Combustible Gas	Propane with purity > 95%
