Programmable Environmental High and Low Temperature Humidity Climatic Test Chamber

Programmable Environmental High and Low Temperature Humidity Climatic Test Chamber
Programmable Environmental High and Low Temperature Humidity Climatic Test Chamber
video play

Large Image :  Programmable Environmental High and Low Temperature Humidity Climatic Test Chamber

Product Details:
Place of Origin: China
Brand Name: ZL
Certification: CE,ISO
Model Number: ZL-6004
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Programmable Environmental High and Low Temperature Humidity Climatic Test Chamber is packaged within wooden case.
Delivery Time: 5-8 work days
Payment Terms: L/C,T/T,Western Union
Supply Ability: 50 Sets
Contact Now
Detailed Product Description
Product Name: Programmable Environmental High And Low Temperature Humidity Climatic Test Chamber Temperature Range: -70℃~+100℃(150℃)
Humidity Range: 20%~98%R.H Accuracy/ Uniformly: ±0.1℃；±0.1%R.H./ ±1.0℃；±3.0%R.H.
Warranty: 12 Months Temperature Limit: The Highest Temperature +150℃; The Lowest Temperature -60℃
Protection Class: Ip67 Voltage: 220V, 380V, 240V, 110V
Highlight:

programmable temperature humidity test chamber

,

high low temperature climatic chamber

,

environmental test chamber with warranty

Programmable Environmental High and Low Temperature Humidity Climatic Test Chamber
This programmable environmental test chamber simulates extreme temperature and humidity conditions to evaluate material performance. It detects changes in materials like rubber, plastic, and electronic products before and after testing, measuring strong attenuation degrees. The chamber can also replicate container environments to assess fading and shrinkage of rubber and plastic under high temperature and humidity conditions.
This equipment tests heat resistance, cold resistance, dry resistance, and humidity resistance of various materials. It is widely used for quality control inspection across multiple industries including electronics, electrical appliances, batteries, universities, research institutes, inspection and quarantine bureaus, paper products, food, vehicles, auto parts, metals, chemistry, and building materials.
Model Specifications
Model ZL-80 (A~G) ZL-150 (A~G) ZL-225 (A~G) ZL-408 (A~G) ZL-608 (A~G) ZL-800 (A~G) ZL-1000 (A~G)
Inside Size W*H*D (cm) 40*50*40 50*60*50 50*75*60 60*85*80 80*95*80 100*100*80 100*100*100
Outside Size W*H*D (cm) 100*170*87 105*175*97 115*190*97 135*195*115 145*185*137 145*210*130 147*210*140
Temperature Range -70℃~+100℃(150℃) (A:+25℃ B:0℃ C:-20℃ D:-40℃ E:-50℃ F:-60℃ G:-70℃)
Humidity Range 20%~98% R.H. (10%-98% R.H./5%~98% R.H. under specific conditions)
Programmable Environmental High and Low Temperature Humidity Climatic Test Chamber 0
Technical Parameters
Inner Box Size and Outer Box Size Inner box size: 400mm * 500mm * 400mm (width * height * depth)
Outer box size: 900mm * 1400mm * 1000mm (width * height * depth)
Inner Box Volume 80L (Dimensions refer to size table above and can be customized)
Temperature Range -60℃ ~ +150℃
Humidity Range 20～98% R.H. (adjustable)
Temperature and Humidity Control Range Programmable Environmental High and Low Temperature Humidity Climatic Test Chamber 1
Control Stability Temperature: ±0.5℃; Humidity: ±2%
Distribution Uniformity Temperature: ±2.0℃; Humidity: ±3.0%
Resolution Temperature: 0.01℃; Humidity: 0.1% R.H.
Heating Time Average 3℃/min, non-linear heating
Cooling Time Average 1℃/min, non-linear cooling
Temperature Limit Highest temperature: +150℃; Lowest temperature: -60℃
Programmable Environmental High and Low Temperature Humidity Climatic Test Chamber 2
