ISO 11358 Thermo Gravimetric Analyzer TGA For Precise Measurements

Large Image : ISO 11358 Thermo Gravimetric Analyzer TGA For Precise Measurements

Product Details:

Place of Origin:	China
Brand Name:	ZL
Certification:	ISO
Model Number:	ZL-3047B

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiable
Packaging Details:	ISO 11358 Thermo Gravimetric Analyzer (TGA) will be Packaged in wooden case （fumigation free）
Delivery Time:	7-10 days
Payment Terms:	T/T, L/C, Western Union
Supply Ability:	100 set per month

Contact Now

Detailed Product Description

Name:	ISO 11358 Thermo Gravimetric Analyzer (TGA)	Temperature Range:	Room Temperature～1250℃
Temperature Resolution:	0.01℃	Temperature Fluctuation:	±0.1℃
Heating Rate:	0.1～100℃/min	Balance Measurement Range:	0.01mg～3g, Can Be Expanded To 30g
Sensitivity:	0.01mg
Highlight:	ISO 11358 Thermo Gravimetric Analyzer , TGA Thermo Gravimetric Analyzer , TGA For Precise Measurements

ISO 11358 Thermo Gravimetric Analyzer (TGA)

Instrument Introduction:

Thermogravimetric analysis (TG, TGA) is to observe the change of sample mass with temperature or time during the process of heating, constant temperature or cooling, with the purpose of studying the thermal stability and composition of the material.

It is widely used in research and development, process optimization and quality monitoring in various fields such as plastics, rubber, coatings, pharmaceuticals, catalysts, inorganic materials, metal materials and composite materials.

Technical Parameters:

Technical Parameters	Basic model ZL-TGA101	Upgrade model ZL-TGA103	Advanced model ZL-TGA105
Temperature Range	Room temperature～1250℃	Room temperature～1350℃	Room temperature～1550℃
Temperature Resolution	0.01℃	0.01℃	0.01℃
Temperature Fluctuation	±0.1℃	±0.1℃	±0.1℃
Heating Rate	0.1～100℃/min	0.1～100℃/min	0.1～100℃/min
Temperature Control Method	PID temperature control, heating and constant temperature
Balance Measurement Range	0.01mg～3g, can be expanded to 30g
Sensitivity	0.01mg	0.01mg	0.01mg
Working Power Supply	AC220V/50Hz	AC220V/50Hz	AC220V/50Hz
Constant Temperature Time	Arbitrary setting
Atmosphere Device	Built-in gas flow meter, including two-way gas switching and flow control
Software	Intelligent software automatically records TG curves for data processing, TG/DTG, mass, and percentage coordinates can be switched arbitrarily
Data Interface	Standard USB interface
Test Range	Thermal stability, decomposition process, adsorption and desorption, oxidation and reduction, etc.
Is it Customizable	customizable
Software	Supporting software, free update and upgrade
Optional	computer
Accessories	Accessory box, one standard substance		Accessory box, one set of standard material, tablet press

ISO 11358 Thermo Gravimetric Analyzer TGA For Precise Measurements 0
