ISO 11357 Plastics Differential Scanning Calorimetry DSC Differential Scanning Calorimeter

ISO 11357 Plastics Differential Scanning Calorimetry DSC Differential Scanning Calorimeter

●Instrument Characteristics:

◆The new metal furnace structure has a better baseline and higher precision. The heating adopts indirect conduction, which has high uniformity and stability, reduces pulse radiation, and is better than the traditional heating mode.

◆Automatically switch the two-way atmosphere flow, with fast switching speed and short stabilization time. At the same time, add a protective gas input.

◆USB communication interface, strong versatility, reliable and uninterrupted communication, and supports self-recovery connection function.

◆Multi-stage temperature setting, fully automatic program control.

◆Industrial-grade 7-inch color touch screen, rich display information, high clarity, and easy operation.

◆The sensitivity of the instrument and the accuracy of measurement are greatly improved. Bidirectional operating system, software real-time acquisition of spectra, online data analysis.

Technical Parameters	ZL-DSC100A	ZL-DSC300	ZL-DSC300C	ZL-DSC300L
Temperature Range	Room temperature～600℃		-40～600℃	-170～600℃
Temperature Resolution	0.01℃	0.001℃	0.001℃	0.001℃
Temperature Fluctuation	±0.1℃	±0.001℃	±0.01℃
Temperature Repeatability	±0.1℃	±0.01℃
Heating Rate/ Cooling Rate	0.1～100℃ /min		0.1～100℃/min/0.1～40℃ /min
Temperature Control Method	PID temperature control, temperature rise, Constant temperature	PID temperature control, heating, constant temperature, cooling
DSC Range	0~±600mW		0~±800mW	0~±600mW
DSC Accuracy	0.01mW
Working Power Supply	AC220V/50Hz or customized
Gas Flow Rate	0～300mL/min
Gas Pressure	≤5mPa
Display Method	24-bit color, 7-inch LCD touch screen display
Data Interface	Standard USB interface
