ASTM D256 Automatic Electric Notch Sample Cutting Machine For Izod Charpy Impact Test

ASTM D256 Automatic Electric Notch Sample Cutting Machine For Izod Charpy Impact Test
ASTM D256 Automatic Electric Notch Sample Cutting Machine For Izod Charpy Impact Test ASTM D256 Automatic Electric Notch Sample Cutting Machine For Izod Charpy Impact Test ASTM D256 Automatic Electric Notch Sample Cutting Machine For Izod Charpy Impact Test ASTM D256 Automatic Electric Notch Sample Cutting Machine For Izod Charpy Impact Test ASTM D256 Automatic Electric Notch Sample Cutting Machine For Izod Charpy Impact Test

Large Image :  ASTM D256 Automatic Electric Notch Sample Cutting Machine For Izod Charpy Impact Test

Product Details:
Place of Origin: China
Brand Name: ZL
Certification: ISO
Model Number: ZL-3040
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: ASTM D256 Automatic Electric Notch Sample Cutting Machine For Izod Charpy Impact Test is packaged within safety wooden case （fumigation free）
Delivery Time: 5- 7 days
Payment Terms: T/T,L/C,Western Union
Supply Ability: 100 set per month
Contact Now
Detailed Product Description
Name: ASTM D256 Automatic Electric Notch Sample Cutting Machine For Izod Charpy Impact Test Model: ZL-3040
Standard: ISO180, ASTM D256,ISO179 Worktable Stroke: >160mm
Feed Speed: 0-30mm/min Adjustable Specimen Type: Type 1, Type 2, Type 3
Notch Type: Type A, Type B (optional), Type C (optional) Brand: ZL
Highlight:

Electric Notch Sample Cutting Machine

,

Automatic Izod Charpy Impact Test Machine

,

Electric Izod Charpy Impact Test Machine

ASTM D256 Automatic Electric Notch Sample Cutting Machine For Izod Charpy Impact Test
Product Overview
The plastic electric notch sample making machine is specialized equipment for preparing notched samples used in impact toughness testing of non-metallic materials. This precision instrument is designed for use with cantilever beam and simply supported beam impact testing machines, serving research institutions, universities, and production facility laboratories.
Download Technical Documentation (PDF)
Compliance Standards
This notch sample cutting machine meets the following international standards:
ISO180-2000 Plastics - Determination of Izod Impact Strength of Hard Materials
ASTM D256-2010 Test method for determining the impact strength of plastic IZOD pendulum
ISO179-2000 Plastics - Determination of Charpy Impact Strength of Hard Materials
Technical Specifications
Parameter Specification
Worktable Stroke >160mm
Feed Speed 0-30mm/min adjustable
Specimen Type Type 1, Type 2, Type 3
Notch Type Type A, Type B (optional), Type C (optional)
Tool Parameters
Tool Type Specifications
Type A Tool 45±1 degree r=0.25±0.025
Type B Tool 45±1 r=1.0±0.025
C1 Type Tool 45±1 r=0.1±0.02
C2 Type Tool Thickness 1=2±0.1 r<=0.1
C3 Type Tool Thickness 2=0.8±0.1 r=0.2±0.05
ASTM D256 Automatic Electric Notch Sample Cutting Machine For Izod Charpy Impact Test 0
