Hand Automatic Melt Flow Index Machine

Hand Automatic Melt Flow Index Machine
Hand Automatic Melt Flow Index Machine Hand Automatic Melt Flow Index Machine Hand Automatic Melt Flow Index Machine Hand Automatic Melt Flow Index Machine Hand Automatic Melt Flow Index Machine Hand Automatic Melt Flow Index Machine

Large Image :  Hand Automatic Melt Flow Index Machine

Product Details:
Place of Origin: China
Brand Name: ZL
Certification: ISO
Model Number: ZL-3014D
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Automatic Melt Flow Rate Tester will be Packaged in wooden case (fumigation free)
Delivery Time: 3-7 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 100 set per month
Detailed Product Description
Product Name: Automatic Melt Flow Index Machine Model: ZL-3014D
Temperature Range: RT-450℃ Temperature Fluctuation: ±0.2℃
Temperature Uniformity: ±1℃ Temperature Display Resolution: 0.1℃
Time Display Resolution: 0.1S Cylinder Diameter: Φ2.095±0.005mm
Output Method: Micro Automatic Printout Cutting Method: Hand-automatic Cutter
Highlight:

Automatic Melt Flow Index Machine

,

Melt Flow Index Machine

Automatic Melt Flow Index Machine





Rubber Testing Machine:

rubber machine.pdf



I. Product description:

This is a high-precision automatic melt flow rate meter tester, for the determination of various plastics, resins in the viscous flow state through a certain temperature and load, every 10min through the standard mouth mold Melt Flow Rate MFR/MVR value, which is applicable to the melt temperature of polycarbonate, polyarylsulfone, fluorine plastic, nylon and other engineering plastics, but also applicable to polyethylene (PE), polystyrene (PS), Polypropylene (PP), ABS resin, polyformaldehyde (POM), polycarbonate (PC) resin and other plastics with low melting temperature test, widely used in plastics production, plastic products, petrochemical and other industries, as well as related colleges and universities, scientific research units and commodity inspection departments.



II. Implementation of standards:

GB/T3682-2018 Determination of Melt Flow Rate and Volumetric Melt Flow Rate of Thermoplastics
ISO 1133:1997 Determination of thermoplastic melt mass flow rate MFR and melt volume flow rate MVR
ASTM D1238 Standard Test Method for the Determination of Melt Flow Rate of Thermoplastics by Extrusion Plastometer





III. Product advantages:

●Multi-segment (2-segment) temperature control mode, 2 groups of platinum resistance sensors, 2 heating jacket separate temperature control, high-precision intelligent PID regulation and control, the slope of the temperature rise that the speed of the temperature rise adjustable



●Temperature resolution of 0.1 ℃, temperature uniformity of 0.2 ℃, temperature fluctuations within 24 hours does not exceed 0.5 ℃, displacement sensor resolution of 0.01 mm.



●Temperature over-temperature protection device



●Hand-automatic cutting material integration, can be arbitrarily set cutting time (0 ~ 999), the number of cutting material (0 ~ 999)



●Test can choose mass method, or volume method, or two test methods at the same time, and can calculate the flow rate ratio. Both methods start the test when the piston rod moves to a certain position.



●Built-in temperature stabilization tips alarm, and add 240 seconds (GB3682 regulations) material preheating seconds countdown, countdown to the end of a beep, can also set the American Standard (ASTM) and other preheating time.

●Built-in a variety of plastic material melt index test conditions, convenient for customers to access at any time to reduce the tedious workload, and storage of the last test conditions and results



●Built-in micro-printer for easy printing of test data



●High-precision touch screen controller, 7-inch touch screen, you can store and print the recent test conditions and data, test print menu settings include test time (system default), operator, material name, test method, test conditions (temperature, weight weight, cutting time interval), test results data, test results of human judgment OK or NG, etc., and so on.



●Reserve RS232 interface or USB interface to connect to the computer, you can control the operation of the instrument through the computer and save the test data transmission to the computer.



●The weights can be loaded manually or through the stepping motor driven ball screw rotation to achieve automatic control of the top loaded weights rise or fall.



●New No.3 steel high temperature corrosion-resistant barrel (optional)



IV. Main technical parameters:



Temperature range RT-450℃
Temperature fluctuation ±0.2℃
Temperature uniformity ±1℃
Temperature display resolution 0.1℃
Time display resolution 0.1S
Cylinder diameter Φ2.095±0.005mm
Outlet length 8.000±0.025mm
Charging cylinder diameter Φ9.550±0.025mm
Accuracy of weights ±0.5%
Output method Micro automatic printout
Cutting method Hand-automatic cutter
Test load Total 8 levels, 8 sets of weights
Supply voltage AC220V±10% 50HZ



Hand Automatic Melt Flow Index Machine 0
