Product Details:
Payment & Shipping Terms:
|
| Product Name: | Plastic And Rubber Torque Rheometer Plus Mixer | Mixer Volume: | 60ML |
|---|---|---|---|
| Rotor Type: | Roller、Banbury、Delta、Cam、Delta、Sigma | Treatment On The Rotors: | Nitridation |
| Heating Rate: | 200℃/11minutes | Cooling Method: | Compressed Air Cooling |
| Torque Measuring Range: | 0~300N.m | Key Words: | Torque Rheometer |
| High Light: | Plastic Rheometer Plus Mixer,Rubber Rheometer Plus Mixer |
||
Rubber Testing Machine
●Product Structure and Technical Parameters
Torque Rheometer Main Control measurement and control host
1. Motor Brand motor: FUji Servo motor Fuji servo motor
2. Power: 4Kw
3. Power source configuration: AC220VNE, 14A, E≤4Ω
4. Computer computer configuration: Dell desktop computer desktop
5. Converter: Schneider
6. Temp. control temperature control: 6 segments
7. Temp. Temperature control range: room temperature to 350°C room temperature to 350°C
8. Temp. control accuracy: ±0.5℃
9. Cooling control cooling control: 4 segments of compressed air 4 segments of compressed air
10. Torque measuring range: 0~300N.m
11. Torque check accuracy Torque measurement accuracy: 0.5%F.s
12. Rotate speed host speed range: 2~200rpm (stepless stepless)
13. Speed accuracy: 0.5%F.s
14. Melt pressure measuring range Melt pressure measuring range: 0~100Mpa
15. Melt pressure measuring accuracy: 0.5% F.S
●Software Software:
1. Measuring and control measurement and control software
2.Mixer data processing system mixer data processing software
3. Extruder data processing system extruder data processing software
4. Polymer melt viscosity measuring data processing system. Polymer melt viscosity measuring data processing system.
●Mixer Torque Rheometer Mixing Device:
| Mixer Volume | 60ml |
| Material | STAVAX stainless steel imported from Sweden ASSAB |
| Rotor Type | Roller, Banbury, Delta, Cam, Delta, Sigma |
| Treatment on the Rotors | Nitriding Nitriding treatment |
| Nitriding Depth | ≥0.2mm |
|
Temp. in the Mixer Cavity Temperature Range |
RT-350°C (3 segments of electrical heater) |
| Temp. Control Accuracy | ±0.5°C |
| Heating Rate | 200℃/11minutes |
| Gear Ratio | 3:2 |
| Torque Range | 0-300Nm |
| Temp. Sensor Temperature Sensor | K-shaped thermocouple K-type thermocouple |
| Heating Method | Electrical heating |
| Heater | Imported heater imported heating tube |
| Total Heating Power of Heating Power | 1700W |
| Heating Range Heating Zone | 3 segments |
| Cooling Method | Compressed air cooling |
