| Power: | 220v 50hz | Temperature: | 50 ℃ ± 2 ℃ |
|---|---|---|---|
| Time Range: | 0-99 Hours. | Marterial: | 304B |
| Temperature Fluctuation: | ± 2 °C | Arranty: | 12 Month |
| Meet Standards: | GB/T2812-2006, GB 2811-2007、ECE、EN、ASTM、JIS、SNELLM2015、AS/NZS 2063 | ||
| High Light: | EN Helmet Testing Machine,ASTM Helmet Testing Machine,Helmet Pretreatment High Temperature Chamber |
||
Main purpose
According to the helmet GB/T2812-2006, GB 2811-2007 production, mainly used to the safety helmet high-temperature pretreatment test. Widely used in special labor protection supplies supervision and inspection stations, building science research institutes, construction quality inspection stations, power departments and helmet manufacturers.
Main features
1.PID number micro computer temperature control, accurate temperature control. Solid state relays, no contact, no spark, explosion-proof, anti-corrosion, safety and environmental protection.
2.With a timing function, regular time can be adjusted. Set time to automatic sound alarm.
3.Strong convection duct design + copper three anti-centrifugal motor, to ensure the continuous circulation of wind and ensure uniform temperature throughout.
4.The use of heating wire heating, electric wire surface area is small, temperature sensitive, small temperature fluctuations, heating speed, cost-effective, low cost after-sales maintenance.
5.Box full CNC brake, high quality welding, to ensure that the angular box, beautiful and generous, the internal use of stainless steel.
6. 3C double tempered glass, high temperature, anti-wear, high transparency and easy to observe the situation inside the test chamber.
7.PT100 metal sensor, test accurately and quickly.
Catalog about Safety Helmet Testing Machine
Safety Helmet Testing Machine.pdf
Main indicators
1.Test temperature: 50 °C ± 2 °C.
2.The temperature range: 0 ~ 200 °C, temperature control accuracy ≤ 1 °C
3.The time range: 0 ~ 99H, can be set, the standard test time 3H.
4.The number of samples: 0-6 top, can be customized according to customer specific needs.
5.The power supply: 220V 50HZ 2KW.
Applicable standards
GB/T2812-2006, GB 2811-2007,ECE,EN,ASTM,JIS,SNELLM2015,AS/NZS 2063
Can be customized according to the above standards
Technical parameters:
| Product Name | Helmet High Temperature Pretreatment Test Chamber |
| High and low temperature pretreatment | Temperature 50 ℃ ± 2 ℃ |
| Time range | 0-99 hours. |
| Warranty | 1~3years |
| Marterial | 304B |
| Temperature fluctuation | ± 2 °C |
| display | Count thermostat |
| Power | AC220V, 50HZ ,1200W |
