PLC Hydraulic Press Rubber Vulcanizing Machine

Large Image : PLC Hydraulic Press Rubber Vulcanizing Machine

Product Details:

Place of Origin:	CHINA
Brand Name:	ZL
Certification:	CE,ISO
Model Number:	ZL-3022

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiable
Packaging Details:	PLC Rubber Hydraulic Press Vulcanizer Machine is packaged within wooden case.
Delivery Time:	5-8 work days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	40 sets / month

Contact Now

Detailed Product Description

Product Name:	PLC Rubber Hydraulic Press Vulcanizer Machine	Temp. Range:	Room Temp. ～300℃
Pressure Surface:	Mirror Chrome Plated	Temp. Controller:	PLC Touch Screen, The Value Indicate Output
Key Words:	Hot Press Hydraulic	Weight:	250kg
Power Supply:	3∮,AC380V,20A	Dimension W×D×H:	1000×500×1500 Mm
Power:	Power
Highlight:	Hydraulic Press Rubber Vulcanizing Machine , PLC Rubber Vulcanizing Machine , PLC Hydraulic Vulcanizing Machine

PLC Hydraulic Press Rubber Vulcanizing Machine

Product Overview

PLC Rubber Hydraulic Press Vulcanizer Machine is designed for placing materials in casting molds, fixed between electro-heated flat plates, applying pressure and temperature to serve as the base for material molding, testing, and mass production components.

Key Features

ZL flat vulcanizer design with compact size and full functionality
Stable temperature control with minimal noise operation
Easy operation for R&D applications with material savings
Accurate temperature maintenance for precise results
Suitable for laboratory research and development

Technical Specifications

Capacity	10~50 ton (Optional)
Temperature Range	Room temperature to 300℃
Temperature Controller	PLC touch screen with value indication output
Timer	LED display, time range 0.1S to 99min to 9.9hr
Heating Type	Electrical Heating module
Hot Pressure Plate	300×300mm (Customizable)
Cold Pressure Plate	300×300mm (Customizable)
Distance of Pressure Plate	100mm
Pressure Material	SKD chromium-molybdenum alloy
Pressure Surface	Mirror chrome plated
Cooling Temperature Scope	Room temperature to +5℃
Cooling Type	Tap water cooling/compressor cooling water (Optional)
Oil Pressure System	Proportion hydraulic pressure current capacity loop circuit control system, GPY oil pump driver high performance with high accuracy non-resistance piston oil cylinder for constant speed rate control mode, capable of pre-selecting pressure and time settings
Oil Cylinder Stroke	Maximum 200mm
Oil Cylinder Speed	11mm/s
Pressure Gauge	0 to 350kg/sq.cm
Power	10.6 HP
Dimensions (W×D×H)	1000×500×1500 mm
Power Supply	3∮, AC380V, 20A
Weight	Approximately 658kg
