| Model Number:: | Double Column Type Spring Tensile Strength Compression Load Testing Machine | Load Cell: | 20KN |
|---|---|---|---|
| Resolution Of Force: | 1/200000 | Accuracy Of Force: | ≤0.5％ |
| Power Magnification: | 7 Automatic Switching | Accuracy Of Extensometer: | ≤0.5％ |
| Testing Width: | 380mm（can Be Increased The Width） | ||
| High Light: | QB/T2710 Tensile Strength Testing Machine,Double Column Tensile Strength Testing Machine,QB/T2710 Tensile Strength Testing Equipment |
||
Equipment summary:
The machine is designed by mechanical-electrical integration, composition of the force-measuring sensor, transmitter, microprocessor, mechanism of load drive , computer and color inkjet printer. High-precision electronic motor can be set to five-speed, the components are connected by plug-way, Floor-standing models, it is taken account of modern industrial design and ergonomics in modeling and coating
It can be tested all the materials in stretch, compression, bending, shear, embedded relay, peeling, tearing, crack, etc,such as rubber, plastics, leather, metal, nylon wire, fabric, paper, aerospace, packaging, construction, petrochemical, electrical, vehicle, etc.
ZL-8001B computer servo type universal testing mac...
Standards and standard configuration:
1. GB/T4689.20-1996 measuring fastness of leather’s adhesion
2. QB/T2710-2005 measuring leather’s expansion and the rate of elongation
3. QB/T2711-2005 measuring tear force of leather
4. QB/T2712-2005 measuring leather’s strength and stretch of spherical crack test
Main Technical parameters about Computer Servo Type Universal Testing Machine
| load cell | 20KN |
| resolution of force | 1/200000 |
| accuracy of force | ≤0.5％ |
| Power magnification | 7 automatic switching |
| displacement resolution | 1/1000 |
| accuracy of displacement | ≤0.5％ |
| resolution of extensometer | 1/1000 |
| accuracy of extensometer | ≤0.5％ |
| Range of speed | 0.01－500mm/min or 1000mm/min(according to the needs of customer) |
| Effective Tensile stroke | 800mm;1000mm;1200mm,(can be increased the height according to customer’s requirement) |
| testing width | 380mm(can be increased the width) |
| power supply | 220V |
| power | about 2KW(depending on different demand of force, using different motor) |
| machine size | about 80x55x220cm(length × width× height) |
| machine weight | About250 kg |
| Units | Kg, N, LB, TON, can be exchanged. |
