25M/Min Plate Chain Conveyor Belt Needle Detector Machine For Meat

Large Image : 25M/Min Plate Chain Conveyor Belt Needle Detector Machine For Meat

Product Details:

Place of Origin:	China
Brand Name:	ZL
Certification:	CE,ISO
Model Number:	ZL-4001

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiable
Packaging Details:	Plate Chain Conveyor Belt Needle Detector For Meat , Sea Food and Vegetables is packaged within wooden case.
Delivery Time:	5-8 work days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	60 Sets

Contact Now

Detailed Product Description

Product Name:	Plate Chain Conveyor Belt Needle Detector For Meat , Sea Food And Vegetables	Display:	Large LCD Display
Detection Height:	8-50cm Customized	Detection Width:	30-80 Cm Customized
Transfer Speed:	25 Meter / Min Or You Can Select Adjust Speed	Alarm Mode:	The Buzzer Alarm, The Motor Automatically Stop
Power:	100-265VAC, 50-60Hz (According To Customer Request)	Key Words:	Needle Detector
Highlight:	25M/Min Needle Detector Machine , 20KG Needle Detector Machine , 25m/min needle metal detector

Plate Chain Conveyor Belt Needle Detector Machine For Meat

Plate Chain Conveyor Belt Needle Detector For Meat, Sea Food and Vegetables

Applications

Widely used in the detection of meat, frozen meat, seafood, mushrooms, drinks, fruits, sugar, salt, and vegetables.

ZL-4001A Conveyor Belt Metal Detection Machine for Food Security Detector

Product Features

Advanced balance theory for reliable detection
Large LCD display with Chinese & English language options
DSP and Microprocessor combination for enhanced detection efficiency
Storage capacity for over 100 product testing data profiles
Advanced error prevention in transmission & reception systems
Phase-adapted technology to effectively eliminate product effect
Self-learning function for automatic product feature recognition
Stainless steel construction with HACCP attestation and IP65 waterproof rating
Customizable automatic rejection system to improve production efficiency

Technical Specifications

Detection Height	8-50cm Customized
Detection Width	30-80cm Customized
Transfer Speed	25 meter/min or adjustable speed
Alarm Mode	Buzzer alarm with automatic motor stop
Size	(150-170)cm(L) * (80-90)cm(W) * (85-120)cm(H)
Power	100-265VAC, 50-60Hz (Customizable)
Reject System	Optional

Detection Sensitivity Specifications

Detected Height (mm)	80	100	150	200	250	300	350
Belt Width (mm)	250	250	400	400	400	400	400
Fe Sensitivity (mm)	0.8	1.0	1.2	1.5	2.0	2.5	3.0
SUS Sensitivity (mm)	1.0	2.0	2.5	2.5	3.0	3.5	4.0
N-Fe Sensitivity (mm)	1.0	1.5	2.0	2.0	2.5	3.0	3.5

Speed: 25M/min (Fixed speed) or adjustable 5-40 M/min
Load Capacity: 20KG
Count: 100
Warning Method: Sound and light alarm with belt control options
Reject Method: Continuous belt operation with product rejection
Application: Non-packaged, plastic packaged, paper bag or box (non-metallic) products
Work Environment: Temperature -10℃ to 40℃, relative humidity 30-90%
