Compact And Rigid Structure Universal Testing Machine / Electro - Hydraulic Rolled Steel Bending Tester

Large Image : Compact And Rigid Structure Universal Testing Machine / Electro - Hydraulic Rolled Steel Bending Tester

Product Details:

Place of Origin:	China
Brand Name:	ZL
Certification:	CE,ISO
Model Number:	ZL-2113

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiable
Packaging Details:	Compact and Rigid Structure Electro-hydraulic Rolled Steel Bending Tester is packaged within wooden case.
Delivery Time:	5-8 work days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	60 Sets

Contact Now

Detailed Product Description

Product Name:	Compact And Rigid Structure Electro-hydraulic Rolled Steel Bending Tester	Max Force:	160kN
Displacement Stroke:	400mm	The Roller Distance:	135-640mm
Bending Angle Range:	0—180°	Max Working Pressure:	31.5Mpa
Main Motor Power:	4kw	Diameter Of Wire Rod:	φ8—φ40mm
Highlight:	tensile test machine , tensile strength testing machine

Compact And Rigid Structure Universal Testing Machine / Electro-Hydraulic Rolled Steel Bending Tester

Product Overview

Compact and Rigid Structure Electro-hydraulic Rolled Steel Bending Tester designed for efficient and reliable bending tests in industrial applications.

Product Features

Compact and rigid structure for convenient and fast bending tests
Hydraulic two-way oil cylinders for fast loading and high efficiency
Pressure sensor device in hydraulic circuit for appropriate bending stress
Quick-change piston front end for rapid specification changes
Exclusive support distance adjustment mechanism with bend stroke adjustment
Bending angle indicator and reverse bending head for accurate testing
Synchronized curved jaw with 180° bend test capability
Photoelectric encoder for precise angle measurement and control
Automatic oxidation leather recycle system with internal feed tray

Technical Parameters

Diameter of wire rod	φ8--φ40mm
Max force	160kN
Diameter of bent roller	36,42,48,54,56,60,64,66,72,75,80,112 mm
Displacement stroke	400mm
The roller distance	135-640mm
Sample thickness × height	(6-40)×50mm
Radius of bent diameter	φ10-φ192mm (optional)
Curved jaw	φ25--φ32mm, 46×265mm
Bending angle range	0--180°
Max working pressure	31.5Mpa
Size (length × width × height)	1250mm × 800mm × 1100mm
Weight	1200KG
Main motor power	4kw
