Solution Compensation High-orecision Multi-function Solid Densimeter

Specifications

DE-200M High-orecision Multi-function Solid Densimeter
1. Manutacturer.
2. Easy operation & maintenance.
3. High Accuracy.

Application:

Powder Metallurgy,magnetic Materials,Hard Alloy,Rubber,Plastic,Wire and Cable,Laboratory,Institute of New Materials Researching and Testing.

Field of quality management,cost control,formula researching and developing,density

test of small products and high-precision products,research of material density.

Standards:

According to the ASTM D792,ASTM D297,GB/T1033,GB/T2951,JIS K6268,ISO 2781,ISO 1183,GB/T208,JB/T7780 standards etc.

Density resolution of DE-200M is 0.0001 g/cm3. No need to open and close the lip with the uni case aluminum alloy board. It is more high-precision,convenient, rapid,hommization. Provide many measuring methods for porosity materials,such as saturation method and surface covering method. Density,open pore volume,total porosity and porosity can be read. It can be used to automatically judge whether the sample is qualified or not,and prompt alarm. It has the function of top and bottom limitation,measuring the volume abrasion value DIN of rubber,measuring expansibility,measuring true density and performance density of powder,measuring oil content of oil bearing,and measuring ceramic desnsity and porosity.

Specification

Density resolution: 0.0001 g/cm3

Maximum weigh:200g

Minimum weigh:0.001g

Measuring range: 0.0001—99.9999g/cm3

Features

No need to open and close the lid; Simple operation;Shorter time; According to the specification of new materials laboratory.

Show the percentage composition of mixed samples for researching and developing new materials.

Apply to powder metallurgy,magnetic materials,ceramics,fireproofing materials,precious metal and so on.

Automatically judge whether the sample is qualified or not and prompt alarm.

Function of solution compensation.necessary if liquid other than water is used as a medium for measuring.

Function of setting actual water temperature,measuring medium density,and water proof medium density.

Function of setting aerostatic buoyancy compensation and the bound of density.

Adopt the uni case high-capacity measuring accessories with the transparent

injection mold tank,which can resist wear,fall off,and corrosion.

Adopt the uni case dedicated wind and dust cover,which makes the combination convenient and durable.

Interface of RS-232C is included.the printer of DE-40 will be available to connect PC with printer.

Standard Accessories:

Host,Tank,Testing board ,Tweezer,Thermometer,100G weight,Wind and dust

cover,A set of measuring grain accessories,A set of measuring floating body

accessories,Power transformer

Measuring Procedure of Hydroscopicity Products:

Place sample on testing board to measure weight in air,and then press ENTER button to memory.

Place sample that did waterproof treatment into water to measure weight in water,and then press ENTER button to memory. Density value is displayed.
