IEC60068 Constant Temperature And Humidity Double Layer Incubator With Glass Door For Lab

Large Image : IEC60068 Constant Temperature And Humidity Double Layer Incubator With Glass Door For Lab

Product Details:

Place of Origin:	China
Brand Name:	ZL
Certification:	CE,ISO
Model Number:	ZL-6036

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiable
Packaging Details:	IEC60068 Incubator Constant Temperature and Humidity Double-layer Incubator With Glass Door for Lab is packaged within wooden case.
Delivery Time:	5-8 work days
Payment Terms:	L/C,T/T,Western Union
Supply Ability:	60 Sets

Contact Now

Detailed Product Description

Product Name:	IEC60068 Incubator Constant Temperature And Humidity Double-layer Incubator With Glass Door For Lab	Inner Box Size:	W×H×D: 300×500×400 (mm)
Outer Box Size:	W×H×D: 1150×2050×780 (mm)	Temperature Range:	-40℃~+100℃
Humidity Fan Range:	20% RH ~98% RH	Internal Material:	SUS #304 Stainless Steel Plate
Control The Surface Of The Board:	Follow The Baking Paint Drawing Above E80308Z
Highlight:	IEC60068 Temperature And Humidity Chamber , Humidity Double Layer Incubator , Temperature Humidity Double Layer Incubator Chamber

IEC60068 Constant Temperature and Humidity Double Layer Incubator with Glass Door for Laboratory

Product Overview

This advanced laboratory incubator features precise temperature and humidity control with a double-layer glass door design for optimal observation and performance in research and testing environments.

View Environmental Testing Chamber Products

Key Features

7.0-inch color LCD touch screen for real-time temperature curve monitoring
Universal castors for easy mobility and positioning
Double-layer door structure with built-in toughened glass door and enlarged perspective windows
Safe and environmentally friendly polyurethane insulation board (moisture-proof, flame-retardant, high temperature resistance up to 250℃)
Optional UV sterilization lamp system available

Technical Specifications

Inner Box Size	WHD: 300500400 mm (2 independent control boxes) or customized size
Outer Box Size	WHD: 11502050780 mm (approximate outer box size)
Temperature Range	-40℃ to +100℃
Humidity Range	20% RH to 98% RH
Control Stability	Temperature: ±0.5℃; Humidity: ±2%
Distribution Uniformity	Temperature: ±2.0℃; Humidity: ±3.0%
Temperature Rise Rate	3℃/min (from -40℃ to 30℃ for about 25 minutes) nonlinear no-load
Temperature Drop Rate	1℃/min (from 30℃ to -40℃ for about 70 minutes) nonlinear no-load
Temperature Limit	Maximum temperature: +100℃; Minimum temperature: -40℃

Construction Details

Internal Material	SUS #304 stainless steel plate
Outer Box Material	Steel plate baking paint (thickness: 1.0mm) according to baking paint drawing C-7138
Electrical Connection	RS232 interface (located behind the control box)
Control Surface Board	Follows baking paint drawing E80308Z
Viewing Window Frame	Follows paint drawing E80308Z
Insulation Material	Hard Polyurethane foam + glass wool
Sealing System	Silicone foam forced tight
Shelves	6 stainless steel shelves with adjustable height (SUS #304 mirror stainless steel)
Heating System	Taiwan imported stainless steel finned radiator U-shaped heating tube (3 groups)
Humidification System	Split humidifier design
Air Circulation	3 motors, stainless steel extended shaft, multi-wing fan blade aluminum alloy wind wheel (SIROCCO FAN), special adjustable 100-page supply air circulation system
Door Configuration	Single door, double door, embedded non-reaction flat handle, four-layer vacuum toughened glass window, electric heating automatic defogging, imported lighting tube
Humidity System	Built-in stainless steel water tank (15L), 3 automatic feed water pumps, water recovery device
