| Product Name: | Rapid Temperature Humidity Controlled Climatic Test Chamber Mini With Humidity Control | Inside Size W*H*D (cm): | 60L (Customized) |
|---|---|---|---|
| Temperature Range: | －10℃～＋150℃±2℃（or Requirement） | Humidity Range: | 30%～95%RH±2%RH（or Requirement） |
| Volatility / Uniformly: | ≤±0.5℃/≤±2℃ | Accuracy: | ＋0.5℃、-3％R.H |
| Material: | SUS 304# Stainless Steel | Cool Speed: | 0.7~1.0℃/min |
| Heat Speed: | 1.0~3.0℃/min | Warranty: | 24 Monthes |
| High Light: | 60L Climatic Test Chamber,SUS 304 Climatic Test Chamber,Tabletop Environmental Test Chamber |
||
Equipment summary:
Tabletop constant temperature and humidity test chamber is widely used in aviation, aerospace, information, electronics, instrumentation and other industries for electrical products, materials, parts, equipment and other accelerated wet and hot test, alternating temperature and heat test and constant humidity and heat test chamber, in order to evaluate the performance of the behavior of the test product under specific environmental conditions.
Environmental Test Chamber Catalog:
Environmental Test Chamber.pdf
Equipment Characteristics:
1, Perfect design: the arc shape and surface coating processing, high body appearance, and USES the plane has no reaction, easy to operate, safe and reliable.
2, Bright, large observation window: three layers of vacuum window and philips energy-saving fluorescent lamps, window without wiper mist, keep clear observation of the effect of the sample (s) to observe the situation.
3, Humidification system pipeline and control circuit separation: humidification system pipeline and power supply, controller, PCB separation, avoid affected circuit by pipeline leakage, improve security.
4, Advanced refrigeration and control system: closed compressor imported from Europe and US, import environmental protection refrigerant, the world famous brand refrigeration devices, original installation import LCD touch screen controller, friendly interface, easy operation.
Corresponding standard:
1, GB11158 high-temperature technical condition.
2, GB10589-89 low-temperature technical condition
3, GB10592-89 high-low-temperature technical condition
4, GB/T10586-89 humidity technical condition
5, GB/T2423.1-2001 low-temperature testing method
6, GB/T2423.2-2001 high-temperature testing method
7, GB/T2423.3-93 humidity and heat testing method
8, GB/T2423.4-93 method of humidity and heat alternating
9, GB/T2423.22-2001 temperature testing method
10, IEC60068-2-1.1990 low-temperature testing method
11, IEC60068-2-2.1974 high-temperature testing method
12, GJB150.3 high-temperature test
13, GJB150.4 low-temperature test
14, GJB150.9 humidity test
Advantages:
1, perfect shape design: circular arc shape and surface spraying treatment, high quality appearance, and the use of flat non-reaction handle, easy to operate, safe and reliable.
2, bright, wide field of view of the large observation window: the use of three-layer vacuum coating window and Philips energy-saving fluorescent lamps, no wiper to remove fog, to maintain a clear observation effect, you can always observe the condition of the test product. 3, humidification system piping and control circuit separation: humidification system piping and power supply, controller, circuit board separation, you can avoid water leakage due to piping and affect the circuit to improve safety.
4,Advanced and reliable refrigeration and control system: original imported European and American fully enclosed compressor, imported environmentally friendly refrigerant, world-renowned refrigeration devices, original imported LCD touch screen controller, friendly interface, easy to learn operation.
Technical parameter:
| Model | ZL-6002 |
| Inside size W*H*D (cm) | 60L (Customized) |
| Temperature range | －10℃～＋150℃±2℃(or requirement) |
| Humidity range | 30%～95%RH±2%RH(or requirement) |
| Volatility / uniformly | ≤±0.5℃/≤±2℃ |
| Accuracy: | ＋0.5℃,-3％R.H |
| heated/cooling | About 4.0℃/min / about 1.0℃/min(specific condition is cooling 5~10℃/min) |
| Heated speed: | 1.0～3.0℃/min |
| Cool speed: | 0.7～1.0℃/min |
| Material | SUS 304# stainless steel |
