220V Packaging Testing Equipment / Automatic Digital Light Transmittance Haze Analyzer For Glass Products

Large Image : 220V Packaging Testing Equipment / Automatic Digital Light Transmittance Haze Analyzer For Glass Products

Product Details:

Place of Origin:	CHINA
Brand Name:	ZL
Certification:	CE,ISO
Model Number:	ZL-9029

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiable
Packaging Details:	Haze analyzer is packaged within wooden case.
Delivery Time:	5-8 work days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	60 sets / month

Contact Now

Detailed Product Description

Product Name:	Haze Analyzer	Accuracy:	Transmittance: 0.1 %; Haze Degree: 0.01 %
Testing Range:	Transmittance: 0-100.0%; Haze Degree: 0-30.00%	Sample Size:	50mm×50mm
Tank Size:	50×50×10mm	Net Weight:	21KG
Power:	220V 50HZ	Environmental Conditions:	10-50°C
Highlight:	paper test equipment , carton bursting tester

220V Packaging Testing Equipment / Automatic Digital Light Transmittance Haze Analyzer For Glass Products

Automatic Digital Light Transmittance Haze Analyzer For Glass Products

DRK122B Haze Meter is designed for testing light transmittance, transmission haze, and reflection haze of transparent and semitransparent parallel level materials and plastic films.

Key Specifications

Light transmittance measurement
Data output interface
Advanced electronic circuit
One year warranty

Product Introduction

The DRK122B Haze Meter conforms to international standards including GB2410-80, ASTM D1033-61, and JIS k7105-81. We also offer the manual DRK122A model that conforms to ASTM D1003-61.

Application Areas

Basic Applications	Extended Applications
Plastic Film Liquid samples Glass Products	Transparent packaging Organic glass Construction material Automotive glass Photographic film

Key Features

Fully automatic operation
LED display showing transmittance and haze degree simultaneously
LPT line print terminal with print interface
Parallel lighting with hemispherical scattering and integral ball photoelectric receiving mode
Advanced electronic circuit for fast measurement speed
Unaffected by environmental light - no darkroom required
Large sample size ensures operator safety

Technical Specifications

Parameter	Specification
Dimension of Sample Room	Window radius: 25mm; Outer window radius: 21mm
Clamp-Houses	DC12V 50W Tungsten halogen lamp + color temperature sheet
Receiver	Silicon photocell + Visual function correction sheet (V(λ) standard value)
Accuracy	Transmittance: 0.1%; Haze degree: 0.01%
Testing Range	Transmittance: 0-100.0%; Haze degree: 0-30.00% (absolute measurement)
Sample Size	50mm × 50mm
Tank Size	50 × 50 × 10mm
Dimension	740mm × 270mm × 300mm
Net Weight	21KG
Power	220V 50HZ
Environmental Conditions	10-50°C
