| Product Name: | Eminex Group Corporate Office Street.2651 Briarhill Lane | Power: | 220v 50hz |
|---|---|---|---|
| Umber Of Test Cup: | 8 Or 12 Cups | Rotation Speed: | 40±2r/min |
| Heating Power: | 4.5 KW +3 KW | Time Control: | 0-99.9min±5s |
| Warranty: | 12 Month | Key Words: | Colour Fastness |
| High Light: | textile testing equipment,abrasion resistance testing machine |
||
1. Applicable Range:
Textile Washing Colour Fastness Tester used for testing the color fastness to washing, drying
cleaning and color fastness to milling of all textiles, and also for assessing the color fastness to washing of
all dyestuffs.
ZL-5007 Colour Fastness to Washing Tester.pdf
2. Relevant Standards:
GB/T3921/1/2/3/4/5 ISO105C01/C02/03/04/05/C06/08 AATCC61/1A/2A/3A/4A/5A JIS L0860/0844
BS1006 etc.
3. Instrument characteristics:
3.1 All stainless steel construction.
3.2 Program controlled by computer, SSR control heating, digital temperature sensor detection
3.3 PID Rregulatoring function
3.4 Direct use of gear, smooth and reliable transmission, convenient replacement of test cup
3.5 Electronic touching switch,LCD menu display,no mechanical contacts,high reliability
4. Technical parameters:
| Product Name | Textile Washing Colour Fastness Tester | |||
| Test cup volume | 550ml;1200mL(matching) | |||
| Number of test cup | 12 | 6(AATCC) | 24 | 12(AATCC) |
| Centrifugal distance | Distance between center of rotation and test cup bottom:45mm | |||
| Rotation speed | 40±2r/min | |||
| Time control | 0-99.9min±5s | |||
| Temperature control | Interior temperature~99℃±2℃ | |||
| Heating power | 4.5 kW +3 kW | 4.5 kW×2 | ||
| Power source | AC380V 50Hz 8kW | AC380V 50Hz 9kW | ||
| External dimension | 935×690×910mm | |||
| Weight | 185kg | 190 kg | ||
