Product Details:
Payment & Shipping Terms:
|
| Product Name: | Drying Electric Motors Industrial Chamber Machine Heat Treatment Oven | Key Words: | Industrial Chamber |
|---|---|---|---|
| Ambient Temperature: | Ambient Temperature | Timing Function: | RT-200 ℃ |
| Temperature Range: | RT-200 ℃ | Temperature Fluctuation: | ≤ ± 2 ℃ |
| Temperature Uniformity: | ≤ ± 5 ℃ | Insulation Materials: | High-quality Cotton Insulation |
| Warranty: | 24 Monthes | ||
| High Light: | SUS 304 Heat Treatment Oven,CE Heat Treatment Oven,220VAC Industrial Drying Machine |
||
Equipment Summary:
High temperature vacuum precision oven is a kind of oven used in high temperature and high vacuum environment, mainly used in material surface treatment, heat treatment, drying, sintering and other fields. Features of high-temperature vacuum precision ovens and applications in different fields:
Vacuum Oven Features:
1, high temperature and high vacuum environment: high temperature vacuum precision oven can be in a high temperature and high vacuum environment for material surface treatment, heat treatment, drying, sintering and other processes, which can improve the physical properties and chemical stability of materials.
2, precision control: high-temperature vacuum precision oven with precision temperature control and vacuum control system, can achieve precise temperature control and vacuum control, to ensure the accuracy and stability of material processing.
3, safe and reliable: high-temperature vacuum precision oven has a safe and reliable design and operating system, which can ensure the safety of the operator and the stable operation of the equipment.
4, Diversification: High-temperature vacuum precision ovens can be customized according to different process requirements, which can meet the needs of different fields.
Corresponding standard:
1, GB11158 high-temperature technical condition.
2, GB10589-89 low-temperature technical condition
3, GB10592-89 high-low-temperature technical condition
4, GB/T10586-89 humidity technical condition
5, GB/T2423.1-2001 low-temperature testing method
6, GB/T2423.2-2001 high-temperature testing method
7, GB/T2423.3-93 humidity and heat testing method
8, GB/T2423.4-93 method of humidity and heat alternating
9, GB/T2423.22-2001 temperature testing method
10, IEC60068-2-1.1990 low-temperature testing method
11, IEC60068-2-2.1974 high-temperature testing method
12, GJB150.3 high-temperature test
13, GJB150.4 low-temperature test
14, GJB150.9 humidity test
Technical parameters:
| Model | Programmable mini temperature humidity chamber |
| Inside size W*H*D (cm) | 40x50x40 |
| Temperature range | -10℃~+150℃±2℃(or requirement) |
| Humidity range | 30%~95%RH±2%RH(or requirement) |
| Volatility / uniformly | ≤±0.5℃/≤±2℃ |
| Accuracy | +0.5℃,-3%R.H |
| heated/cooling |
About 4.0℃/min / about 1.0℃/min (specific condition is cooling 5~10℃/min) |
| Heated speed | 1.0~3.0℃/min |
| Cool speed | 0.7~1.0℃/min |
| Material | SUS 304# stainless steel |
| Controller | Touch Screen Controller for South KoreaTEMI |
| Sensor | PT100Ω/MV |
| Insulation material |
High-temperature high-density amino acid ethyl ester foam insulation materials |
| Heated system | Nickel-chromium alloy electric heating type heater |
| Humidity system | Stainless steel surface evaporative humidifier |
| Cooling system |
Totally enclosed air-cooled single-stage compression refrigeration method/ Original French "Taikang" / Totally enclosed air-cooled re-compression refrigeration methods Diego |
| circulatory system |
low-noise air-conditioning-type motor. Multi-vane centrifugal wind wheel |
| Safe device |
Leakage and over-load protector, compressor-overload protector, over warm, wet and power protector, overheating protector, the over-temperature protective device |
| Fitting |
recorder(purchase),view window,50mm testing hole, PL lamp,clapboard,Dry and wet gauze ball |
| Compressor | France“Taikang” |
| Power |
1Φ 220VAC±10% 50/60Hz |
