| Product Name: | Laboratory Moving Die No Rotor Rubber Plastic Rheometer Programmable Rotorless Price | Meet Standard: | GB/T16584, ISO6502:1991 And ASTMD5289-95 |
|---|---|---|---|
| Temperature tester: | Room Temperature To 200°C | Heating Speed: | Room Temperature—200℃,about 10 Min |
| Temperature accuracy: | ≤ ±0.1°C | Temperature resolution: | 0.1°C |
| Torque Range: | 0-5N.M、0-10N.M、0-20N.M (option) | Torque Resolution:: | 0.001NM |
| Motor rotating speed: | 100 Times / Min | Rotor type: | Rotor Less |
| High Light: | Moving Die Rubber Rheometer,No Rotor Rubber Rheometer,Rotorless Rubber Testing Machine |
||
Download Brief:
ZL-3001 No Rotor Rheometer.pdf
Use:
This machine is designed by GB/T16584<Rubber——use no-rotor rheometer to test vulcanization characteristic,can meet ISO6502 standard,and can test the data of Italy standards about T10,T30,T50,T60,T90.This machine can be use test unvulcanized rubber characteristic,and test out the suitable vulcanizing time. Used imported intelligent digital temperature controller,easy adjustment,wide temperature controlling range,high accuracy,good stability and reproducibility.Use computer to control the machine and store the test data and print the data.Test curve can be compared and amplification in software.
Applicable industry:
Widely used in rubber products industries.
Technical parameters:
| Model | ZL-3001 No Rotor rheometer |
| Meet standard | GB/T16584, ISO6502:1991 and ASTMD5289-95 |
| Temperature tester | Room temperature to 200°C |
| Heating speed | room temperature—200℃,about 10 min |
| Temperature accuracy | ≤ ±0.1°C |
| Temperature resolution | 0.1°C |
| Torque range | 0-5N.M,0-10N.M,0-20N.M (option) |
| Torque resolution: | 0.001NM |
| Motor rotating speed | 100 times / min |
| Rotor type | Rotor less |
| Die body pendulum | 1.7Hz±0.1Hz(100r/min) |
| Rotor pendulum angle | ±0.5°, ±1°, ±3° |
| Testing time setting | 3min--120min,choose freely |
| Air compression | 0.5Mpa--0.65MPa |
| Ambient temperature | 0-35°C |
| Test result | Printing:date,time,temperature,vulcanization curve,temperature curve,ML,MH,ts1,ts2,t10,t50,Vc1,Vc2. |
| Consumption power | 800 w |
| Dimension | 640mm×580mm×1300mm |
| Power | Single phase, 220V±10%, 50Hz |
| Display | Windows 7 + software |
| Weight | 260kg |
