Product Details:
Payment & Shipping Terms:
|
| Product Name: | Lab Vacuum Platen Tyre Vulcanizing Press Machine For Rubber Plastic | Platen Size: | 300*300mm Or Customized |
|---|---|---|---|
| Press Layer: | Single / Double | Power: | 10.6HP |
| Pressure Material: | SKD Chromium-molybdenum Alloy | Pressure Gauge: | 0~350kg/sq.cm |
| Capacity: | 300T | Key Words: | Vacuum , Vulcanizing |
| High Light: | rubber testing equipments,rubber hardness tester |
||
Lab Vacuum Platen Vulcanizing Press Machine for Rubber Plastic
Instruction:
Lab vacuum Platen Vulcanizing Press Machine is placed in the casting mold and clamped between
the electric-heating flat plates to apply pressure and temperature,make the material shaping,testing and
serving as the basis for the ingredient of mass production.
Parameters:
| Product Name | Lab vacuum Platen Vulcanizing Press Machine for Rubber Plastic |
| Capacity | 10T/20T/30T/50T/300T (Can be customize) |
| Temp. Range | Room temp. ~300℃ |
| Temp. Controller | LED Indicator,press key set input, the value indicate output |
| Timer | LED display,time range 0.1S~99min~9.9hr |
| Heating type | Electrical Heating module |
| Hot pressure plate | 300×300mm, 350*350mm |
| Cold pressure plate | 300×300mm, 350*350mm |
| Distance of pressure plate | 100mm |
| Pressure material | SKD chromium-molybdenum alloy |
| Pressure surface | Mirror chrome plated |
| Cooling temperature scope | Room temp. ~+5℃ |
| Cooling type | Tap water cooling/compressor cooling water(optional) |
| Oil pressure system |
The proportion hydraulic pressure current capacity loop circuit control system,the GPY oil pump driver high performance electroencephalographic matching high accuracy non resistance piston of oil cylinder carry out constant speed rate control mode, can preelection one, two times pressure and time. |
| Oil cylinder stroke | Max 200mm |
| Oil cylinder speed | 11mm/s |
| Pressure gauge | 0~350kg/sq.cm |
| Power | 10.6HP |
| Dimension W×D×H | 1200×600×1500 mm |
| Power supply | AC380V,three phase 60hz |
| Weight | About 750 kg |
FAQ
1. What is the order process?
Inquiry - quotation - communication - order confirming - deposit payment - production - testing and debugging - balance payment - packing - delivery - customer receiving - after service.
2. How about the packing for machine, is it safely protected during transportation?
Our machine is packed by standard export wooden box, it won’t be damaged. We’ve delivered many testing machines abroad by sea or by air without damage.
3. Do you accept customization service?
Yes, of course, we can not only offer standard machines, but also customized machines
according to your request. Don’t hesitate to tell us your requirement, we will try our best to meet your needs.
4. Do you have customers of our country before?
Now our testing machines have been sold to more than 95 countries, like USA, Canada, Russia,UK, Italy, Germany, European , India, Pakistan, Philippine, Singapore, Malaysia,Thailand , Vietnam, Korea,Saudi Arabia,Brazil...and so on.
5. How about your warranty?
Generally,our warranty is two years. Within the warranty period, we can offer technique support and part parts change, necessarily, our engineers may go to your place for better service.
6. What’s the delivery term?
At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15~20 working days after deposit receipt. If you are in urgent need, we can consider making special arrangement for you.
